Test Cast and QC Sign-Off: Shot List, Real Dump, Written Note
Approving a hero photo while missing flash and island tears is how production diverges from the sample. If you are at QC sign-off, the test cast is your pour - pectin, chocolate, resin, wax, soap, plaster, or concrete - at real temperature, with a written pass/fail and a shot list (grams, peel, keys, logo, flash). A three-quarter grey cavity photo is not a golden sample. This service is the photography and the yes/no that starts MOQ 20.
RUUIPON runs that sign-off in Bao'an, Shenzhen (Licheng Technology Industry Park, Xinhe Blvd, Shajing; USCC 91440300MA5FAXCN9W) since 2018. Simple 3D is USD 50 when that CAD scope applies. The prototype window is 3-7 business days after CAD lock. Production is MOQ 20 pieces per design after the note. LSR part FAI belongs here as an HTV product RFQ.
Where this service sits
What a first tool is lives on silicone mold prototype. What to measure on tray 1 lives on prototype inspection CTQ. The buyer gate before multiplying is approve before production. Incoming / outgoing lot inspection is silicone mold quality control. This service covers the commercial sign-off path: the shot list you attach to the sample you hold, and the one-line reject.
Shot list we need with the sample
Five consecutive pulls beat one hero crop. Tear often shows on pull 3-5, not pull 1. If the SKU is chocolate, send tempered chocolate or say you have not poured yet. Hobby resin on a chocolate tool teaches the wrong stick.
| Shot | What it must show | Fail if |
|---|---|---|
| Revision letter vs master | Same ID on skin, jacket, and note | Unsigned crop, no revision |
| Tray top and bottom | Warp, contamination, jacket seating | Beauty angle that hides the base |
| Cavity macros | Islands, pits, texture | Soft focus over the logo |
| Parting line / shut | Flash location vs cosmetic face | Flash cropped out |
| Keys assembled and open | Whether a key walks or seats 180 wrong | Empty tray only |
| Five consecutive casts | Peel path, tear start, stretch | Pull 1 only |
| Scale / grams | Named cavities, measurement state | No weights when grams are commercial |
| Logo fill in the real dump | Complete counters, no starved serifs | Empty recess as proof |
A useful note reads like this: Revision B dumped in pectin. CTQ weights passed on cavities 1, 6, 12 (jacketed). Released without abnormal stretch. Key 3 walks; recut before production.
Sign-off criteria
- Pass sentence in the intended dump, not in water.
- CTQs named with relaxed / jacketed / loaded.
- Structure matches production: split, keys, jacket, cavity count.
- Reject is one line: flash / tear / grams / OD - not a mood board.
- Who signs, and where the paper and golden sample live for reorder.
Shore after your pour can stay in the same CAD. A hidden hook is a CAD reopen. A units miss is a CAD reopen. Prototype is typically 3-7 business days after the new lock if CAD reopens.
Typical shop values
Reference values only. Confirm material-specific limits against the supplier’s technical data and agree project acceptance criteria before production.
| Item | Typical shop value |
|---|---|
| Prototype / sign-off clock | 3-7 business days after CAD lock |
| Production after the note | MOQ 20 pieces per design |
| 3D / CAD | USD 50 when that modeling scope applies |
| Mix / shrink | Platinum 1:1 or 10:1; about 0.1-0.3% |
| Loaded sag / outer-row | About 0.5-1.5 mm; often 3-6% heavy if sagging |
| Cavity Shore | Often 10A-20A; jacket if loaded |
| Contact | [email protected] · +86 135 3006 2969 |
Reject vs nudge vs reopen CAD
A Shore band change after a real peel can stay on the locked solid. Flash on a named equator can be trim-ok if you write it. A walking key, a starved logo, or a systematic gram miss is a recut. Write flash / tear / grams / OD in one line. A lighting complaint is not a reject.
Worked example: chocolate bar, temper dump
Typical job, not a named customer. Buyer wanted to approve from a render. We required a temper dump, weighed bars, marked equator flash as trim-ok, rejected a seam that walked onto the wordmark, recut keys, then MOQ 20. The beauty shot would have missed the walk. Witness pour at RUUIPON only if we agreed it; default is your chemistry.
When this sign-off is the wrong ritual
A catalog ice tray that already matches does not need this service. Lot sampling on a repeat PO belongs on quality control, not a second sign-off novel. LSR FAI is a different RFQ - ask us. Geometry can override quantity: one split sculpture still needs a real pull and the shot list.
RFQs we will not accept as-is
A WeChat "looks good" as the golden sample. Water as the test cast on pectin, epoxy, or concrete. Multiplying before the note. A hero crop that hides flash. Sending an LSR part FAI through this RTV sign-off.
Matched next step
Send the shot list plus the one-line reject or pass, STEP revision, pour and peak C, and quantity after approval. We will say whether the next move is a Shore nudge, a recut, or MOQ 20. A lighting brief is not a sign-off pack.
Send the shot list and pass/fail line · Prototype hub · Quality control · Approve before production
[email protected] · +86 135 3006 2969 · Licheng Technology Industry Park, Xinhe Blvd, Shajing, Bao'an, Shenzhen. USCC 91440300MA5FAXCN9W.
FAQ
Does reject restart MOQ 20? Prototype is not the production lot. Production MOQ 20 still applies after you approve.
Witness pour at RUUIPON? Only if we agreed it. Default is your chemistry.
Same as the samples hub? Samples is the commercial samples URL. This is QC photography and sign-off.
Is a video enough? Video plus weights and a sentence. Video alone is still a photo.
Different dump later? New sign-off. Chemistry lock first.
